Description

1 Introduce

This is a three sides seal bag well prepared for rice 5kg, which is quite famous in the consumer market for rice products and young people. The main body is set in yellow, which attracts so glamorous rice products and young people.

Here we will give a further analysis on this amazing rice bag, and hope you will get a fantastic package for your products.

Watch the video for thisextraordinary rice bag.

2 Foil Materials

This foil material is a reinforced structure with excellent properties for rice packages. The foil structure is PA/LDPE, with a graphic as below.

Let’s first get a further understanding on each substrate layer material.

PA stands for Biaxially Oriented Polyamide, which is also known as biaxially oriented nylon (short as NY) film. It’s a versatile and flexible material that’s made by biaxially stretching polyamide resins using a flat cast die process, three-layer co-extrusion method, and two-step tenter frame orientation.

PA film is especially popular for food packaging because it can help keep food fresh and can display important information like whether the product is organic, vegetarian, or halal, and if it contains allergens. The growing demand for packaged food and the pharmaceutical industry are expected to drive the growth of the BOPA film market in the coming years.

LDPE, means low-density polyethylene film, which is the most used inner sealing layer for coffee bags. LDPE is also lightweight, easy to fabricate, and has good chemical and impact resistance. LDPE is recyclable and reusable, making it a popular alternative to traditional plastic. LDPE is nontoxic, non-contaminating, and has a high degree of break resistance. Most importantly, LDPE membrane can be modified against the requirement of specific products, and finalize the package with great seal strength and protection. The thickness of LDPE membrane will be decided against particular

3 Properties and Quality Assurance

3.1 Exquisite print quality

The artwork is achieved in gravure printing on our rotogravure print press which can print up to maximum 10 colors. With advanced print techniques and print defects inspection system, we are now outputing fantastic print effects for the customers’ artwork.

In our manufacturing plant, we take serious measures to achieve high color fidelity and consistency for repeated printed orders, and here we are going to give a basic introduction.

a.  Color Analyzer

This color analyzer is one of the auxiliary tools in our system to achieve the highest standard for color fidelity. The eXact Advanced doesn’t just validate the color of CMYK and spot color inks, it can simultaneously measure four M modes to visualize the spectral reflectance of a substrate or ink, measure the concentration of a specific ink, and measure the difference of a substrate or ink over white and over black.

b. Pantone Color Code

Pantone color guide would be so helpful to locate a specific color for the pring service supplier and the customers, especially there is a large area printed in single Pantone color. For many Pantone colors, the accurateness may be influenced by the printer, paper substrate and environmental factors when it is printed onto physical photo paper. We will locate the Pantone Color Code with the customers in their artwork design before the order is put into produce.

c. Physical Printed On Photo Paper

The computer files such as JPG, PDF, PSD, AI etc can not be taken as the guide to determine the color in print produce, as they present the colors through electronic screening devices. And different electronic screens may be set in different parameters by the various manufacturers, which will inevitably interfere with the colore presentation. Artwork can only be a reliable guide when printed on physical substrate, with the most common photo paper applied.

You may read here to understand more about how our company ensures color fidelity and consistency for all our orders.

Measure taken to achieve high color fidelity and consistency in reprints



3.2 Excellent Dimension Stability

There is an increasing requirement for the dimension stability of the rice bags when the roasters and packers are going to improve the production efficiency with high-speed filling lines. We get quite a good understanding on this ,and are doing our job to narrow the tolerance of the dimensions for each order produced in our long-term supply. Usually for the 5kg rice bag, the tolerance should be controlled within +-2%, which can run well on most of the high-speed filling machineries in the market.

3.3 Delicate Bag Making

The bag is achieved with delicate details, which can create a perfect impression for the consumers when they pass by the products, and cause them a purchase. Some customers do like to buy a product out of its gorgeous profile.

3.4 High Barrier Performance

As explained previously, this foil laminate is finalized with a layer of thin aluminum metal sheet, which is of the best barrier performance against oxygen and moisture vapor. Usually, the roasted beans should be well protected to keep the original flavor and fragrance for a prolonged period, to enable the beans enjoyed by the end consumers.

3.5 Great Mechanical Strength

This reinforced laminated foil can greatly protect rice ranging from 100g to 5lb volume.

We perform various inspections and tests to check the mechanical strength of the finished pouch, like drop tests, hard sudden strikes, anti-pressure tests

• Tensile Strength
• Sealing Strength
• Anti-puncture Strength
• Burst Impact Strength
• Anti-pressure Property

The above tests are performed against each order, on customer requirements, and you may check the exact values of this foil material PA/LDPE in the Technical Date Sheet part of this post.

4 Quality Control Measures

Serious quality control measures have been taken in our manufacturing plant, to ensure each order is finished meeting the requirements of particular customers. With more than ten years of working experience in this field, we finalize this QC manual standard, to make sure each order is produced following the correct procedure.

Here, please allow us to guide you further into our QC system.

4.1 Manufacturing Traceback

We apply a strict recording system to document the manufacturing details, such as environmental conditions, craftsmanship parameters, production facility conditions, etc, which allows us to trace back whenever there is a problem.

4.2 QC Test Report Against Each Order

There will be a QC test report issued against each order produced, with the core items evaluated in it.  It is highly appreciated by our customers.

You may read here to understand the QC test report .

4.3 Print Inspection

In our manufacturing plant, the print inspection is always taken and done in a serious way, as we will never allow the customer artwork to be achieved in a way that deteriorate their business. On our gravure print press, there is in-line inspection system which can eliminate more than 98% of the defects in the printing process.

You may check how it works on our control panel.



There is also a supplementary off-line inspection equipment, to allow us to do the print inspection again whenever it seems necessary.

We are now producing bags against customer artwork, and we surely love to support the startup and market-testing period for our customers. We will accept a minimum order quantity of 10,000 bags printed against customer artwork design.

4.4 Airtight Property Test

The finished coffee bag should be completely airtight, to get the products well-protected from oxygen and moisture in the environment. We perform the airtight property test against each order with the device as below.

In actual operation, we will pick up 1 bag every 1,000 pcs, and perform the test following the procedure in our QC manual.

4.5 Gas Release Property Test

The gas will be released from the inside when the air pressure for the inside is 2~7 mbar than the outside environment. Usually, we will immerse the valve welded bag under the water, and check if the degassing valve works well.

4.6 Drop Test

Drop test should be considered as a very reliable way to check if the rice bag strength is enough to meet the various conditions, as it copies the way when the products falls off the good shelves, and the finished bag will suffer great sudden shock. In our daily QC work, We perform drop test against each order, of course, the standard for this drop test should be decided against customer needs.

You are advised to watch the video below, for a further understanding.



4.7 Hard Sudden Strikes on inflated rice bags

Hard sudden strikes should be taken as a more fierce test method than drop test, as it causes much higher force on inflated packages.

Let’s watch the video to understand how we perform this test in our manufacturing plant.

4.8 Anti-Pressure Test

Pressure-resistance test is another effective method to decide if the final package will serve as great protection for the products, especially liquid products, like household detergent liquids, and windshield washer fluids. For rice pouch, we will perform the anti-pressure test in our daily QC work, to ensure each order is finished with great mechanical strength.

The leakage or breakage of the coffee bag will surely be a disaster, either for the distributor or the manufacturer.  We will never expect this thing happens in our customer’s business.

Sometimes, for easier and fast operation, we may just get one person to stand on the well-sealed and inflated coffee bag, to check if there is any burst of them.

4.9 Laboratory Tests

Laboratory tests are essential to keep us updated with the intrinsic properties of the foil materials which are not visible to the human eyes. It is crucial for gaining a thorough understanding of the data about the production of our bags. The craftsmanship can be improved bit by bit to pursue premium quality bags based on thorough analysis and application of these data. You may check more of these tests in the Technical Data Sheet part of this post.

4.10 Third-party Inspection

Third-party inspection is available for all our orders on agreed standards or regulations.

5 Human Food Safety

All the film materials, inks, adhesives, and solvents used to convert into kinds of food bags and packaging materials will comply with the regulations for human food safety. The below graphic shows the mass spectra in migration tests on these multilayer flexible pouches these are in direct contact with foods.

Through the below link, you will be able to study the certificates on each of the materials adapted in our factory.

Human Food Safety

6 Dieline of Plastic bag for 5kg rice with handle hole

The die-line of this 5kg three sides  seal rice bag is essential when the customers want to achieve a fantastic artwork design for their package. All the details, like dimension, valve position, zipper position are well stipulated in this die-cut line.

We attach the editable PDF file here, and the customer can just download and forward it to his designer for further creative work.

Design Template 12oz coffee beans W125XH230+Gusset80+Flat Bottom Pouch

7 Technical Data Sheet of Plastic bag for 5kg rice with handle hole

Here, we include the specifications on some main items of this multilayer coffee bag, with the videos showing the test progress in the later columns.

Some main items are listed below.

1. Dimension Tolerance
2. Print Appearance
3. Yield (grams per square meter)
4. Tensile Strength (Mpa)
5. Elongation Rate  (%)
6. Coefficient of friction, short as COF
7. Solvents Left (mg/m2 )
8. Sealing Strength (N/15mm)
9. Sealing Conditions
10. Bond Strength (N/15mm)
11. Burst Strength (J)
12. Anti-Puncture ability (N)
13. Drop Test Ability (cm)
14. Anti-pressure ability (kgs)
15. Water Vapor Transmission Rate (g/m2/24hr)
16. Oxygen Transmission Rate (cc/m2/24hr)

Just reach us if you have any questions with any of the items.

8 More Sustainable Options

With the increasing burden on plastic pollution, more and more manufacturers are now seeking more sustainable packages, like compostable film materials, recyclable mono materials packages, and plant-based materials packages. They all prove to be more eco-friendly and sustainable than the traditional plastic films which are usually derived from fossil chemicals, and very difficult to recycle and break down in the environment.

Here, we are going to share some of the trending sustainable packages for the coffee market.

8.1 Compostable film material packages

Thanks to the fast development of plant-based film materials, we can present the multi-layer standup pouch and roll foils in full compostable and biodegradable options.



The compostable substrate films we adapt to convert the multi-layer flexible pouches are listed below.

1. BOPLA Film
2. PLA+PBAT Film
3. Kraft Paper
4. Metallized Paper
5. Cellulose Film
6. Metallized Cellulose Paper
7. PBS Film
8. PVDC Coated Cellulose Film
9. Metallized BOPLA Membrane

We are now achieving multilayer compostable foil materials based on extrusion coating lamination, solvent-free lamination and dry lamination, and then convert into various types of flexible pouches against customers’ requirements.

Some of the common compostable foil structures are listed below.

• Kraft Paper/PLA+PBAT Membrane
• Kraft Paper/BOPLA Membrane
• Cellulose/PLA+PBAT Membrane
• Kraft Paper/PBS Foil Membrane
• Metallized Paper/PLA+PBAT Membrane
• BOPLA/PLA+PBAT Membrane
• Cellulose/Metallized Cellulose/PLA+PBAT Membrane
• Kraft Paper/Metallized Cellulose/PLA+PBAT Membrane
• Cellulose/Metallized Paper/PLA+PBAT Membrane
• Kraft Paper/Cellulose/PLA+PBAT Membrane
• Kraft Paper/Cellulose/PBS Membrane
• Metallized Paper/Cellulose/PLA+PBAT Membrane

Here, we are going to introduce the main performance of these compostable materials pouches.

a. Compostable

All the film materials we adapt are certificated compostable, under home or industrial conditions, complying with the standards EN 13432 or ASTM 6400.





















The films will present different biodegradation behaviors under different conditions, such as industrial composting facilities, home and garden conditions, and nature soil conditions.

In most cases, industrial composting will be able to achieve a faster biodegradation of the compostable film materials than other composting progress, as it is able to provide better conditions.

Some manufacturers would like to have a better biodegradation behaviors of their own compostable packages under nature soil conditions, as in most cases, the abandoned package may not be recycled into human composting facilities.

You may read here to have a better understanding of the break-down progress of our compostable foil laminated materials under the nature condition in Qingdao, Shandong, North China conditions.

The biodegrading process of compostable film materials buried in nature soil

b. High-barrier performance pouches

Through vacuum metallization, PVDC coating, and AlOx/SiOx depositing, the compostable films can be achieved with better barrier performance, such as water vapor transmission rate (short as WVTR) and Oxygen Transmission Rate (short as OTR). Later on, we will combine several layers of the barrier film and convert into laminate foil, with an improved barrier property for finished packages.odles, or soup products

In below table, we are going to share some barrier data of the most common foil laminates tested on our Mocon permeation tester.

Biodegradable Foil Laminate	WVTR (g/m2/24hr)	OTR (cc/m2/24hr)
BOPLA40/PLA+PBAT60	62.2	267
Cellulose30/PLA+PBAT60	131.5	5.6
Kraft Paper45g /PLA+PBAT60	44	742
Kraft Paper45g/BOPLA40	41	380
Metallized Paper69g/PLA+PBAT40	27	127
Cellulose30/Metallized Cellulose20/PLA+PBAT60	23	0.16
Cellulose30/Metallized Cellulose20/BOPLA40	25	0.12
Metallized Paper 69g/Cellulose30/PLA+PBAT60	5.6	1.12
Kraft45g/Metallized Cellulose20/PLA+PBAT60	26	0.22
Cellulose30/Kraft45g/PLA+PBAT60	19	117.2
Cellulose30/Metallized Paper69g/PLA+PBAT60	8.9	1.1

c. Alkaline Resistant

We put a certain amount of bleaching powder into the compostable pouches with various foil structures, and place them in an environment of 40~45 Celsius degree, to accelerate the aging process of the compostable pouches.

The test result proves the compostable pouches will be fine for packing alkaline products, like household detergent powder, and hand wash cubes.

However, it is not ok for household liquid detergent and other liquid cleaning chemicals.

You may watch the video below for further knowledge on it.

d. Frozen Treatment

The compostable pouches can be well intended for frozen treatment for some food products, and the mechanical property of the frozen pouch still works well as good protection for the products during the transportation and distribution process.

You may watch the video below to study the test in our office.

d. Vacuum Packages

The compostable pouches can be intended for the vacuum packages for products, like milk powder, nutrition products, etc.

f. Hot Filling up to 100 Celsius Degree

The compostable pouch will be fine for the hot filling process, which may work well for juice products.

Watch the video below to learn our test.

g. Microwave Oven Treatment

The compostable doypack can be well intended for microwave oven treatment, such as melting the candle wax, etc.

Please note, there should not be metalized film layer in the compostable pouch when it is intended for this microwave treatment purpose.

You may read here for better understanding on the compostable plant-based film materials packaging.

Compostable Plant-film Materials Pouch Packaging

8.2 Mono Materials Recyclable Pouch Packages

Mono meterials pouch packages are truly recyclable, as they can be easily processed into plastic granules which can be used again for other applications. However, for the traditional multilayer laminates, take PET/LDPE for example, it is difficult to process, as PET and LDPE are quite different materials, and can not be melted under the same conditions. That’s why momo materials pouch packages are becoming so widely popular in the packaging field, and highly reputed in the consumer market.

At present, mono-materials pouches are divided into Polyethylene channels and Polypropylene channels, with polyethylene channels much more popular, as they can be converted into kinds of standup pouch packages with relatively high performance.

Here we list the film materials that can be well intended for mono-materials recyclable pouch packages.

1. MDOPE Film
2. BOPE Film
3. APE Film
4. LDPE Film
5. LLDPE Film
6. CPE Film
7. ABOPP Film
8. CPP Film
9. VMCPP Film
10. VMBOPP Film
11. EVOH-LDPE Film
12. HDPE Film

Various foil laminates can be achieved based on the above film materials with different properties, which are intended to meet the particular requirements for specific products. Some of the common mono-material foil laminates are listed below.

1. MDOPE/APE
2. MDOPE/LDPE
3. MDOPE/EVOH-LDPE
4. MDOPE/HDPE/APE
5. MDOPE/BOPE/APE
6. BOPE/APE
7. BOPP/CPP
8. BOPP/VMCPP
9. ABOPP/VMCPP

From our experience, mono-materials pouches can be well intended for spices powder products.

You may have a further understanding of the recyclable mono materials and pouches here, and just reach us if you have any questions

Fully Recyclable Mono Materials Package

9 Reliable filling machinery to fill products into this flat-bottom coffee pouch

Our bags are produced for running on the high-speed filling lines, which maximize the production efficiency for the coffee roasters. Of course, you will have to find a reliable filling machinery to do this job.

Here, we will share with you a reliable filling line to carry on the work of filling beans into flat bottom coffee bags.

Enjoy!

10 About the manufacturer

Qingdao Tongli Packaging has devoted itself to the manufacture of quality coffee bags for more than 10 years, with long-term customers around the world. You may just rely on us if you would like to get a sustainable and reliable supply for your coffee packages.
