Description

Watch the video for this glossy custom printed metallised film foil roll for 5 grams medicine tablet 3sides sealed sachet

Introduce

This lovely roll film is well intended for the premium quality sachets of medicine tablet 5 grams. It runs well on the vertical-form-fill-seal line and be converted into 3sides sealed sachet.

Here we are going to give a further explaination on this amazing roll, and hope it helps you to decide your perfect package.

Foil Structure

This foil materials is a reinforced structure with excellent properties for medicine tablet. The foil structure is Matte BOPP18/White Kraft45g/AL7/LDPE, with graphic as below.



Matte BOPP18, is short for matte finish biaxially orientated polypropylene film with most common thickness 18 microns (equals to 0.72 gauge). Compared to glossy BOPP film, it is able to achieve the final package with a fine matte visual appearance for the package at a lower cost.



Al7, is short for aluminum foil metal sheet with thickness 7 microns, which is the most common used thickness in flexible packaging. It is of the best barrier performance among all the film materials, which can keep the orginal flavor and fragance for a prolonged time.

LDPE film, means low density polyethylene film, which is the most used inner sealing layer for the coffee bag. It is able to provide enough sealing strength and airtight property for the final packages.

The final thickness for this foil laminate should be 65 microns, with tolerance +-5%. and the toughness of this foil will be enough to finalize good package profile for 10ml of medicine tablet.

Medicine Tablet Rolls Properties

1 Great print quality

The artwork is achieved in gravure printing which can print up to maximum 10 colors. With advanced print techniques and print defects inspection system, we are now outputing fantastic print effect against the customers’ artwork.

2 Enough Barrier Performance for Medicine Tablet

With mocon O2/H2O/CO2 permeation tester equiped in our laboratory, we are able to keep a more close eye on the barrier performance of each laminate foil produced in our manfuacturing plant.



Below table shows the WVTR (short for water/moisture vapor transmission rate) and OTR (short for oxygen transmission rate) against foil laminate Matte BOPP18/White Kraft 45g/LDPE

Item	Standard	Unit	Value
WVTR	ASTM E 96	g/m2/24hr	1.05
OTR	ASTM D 372-99	cc/m2/24hr	0.95

This foil materials proves to be working well for medicine tablet distritubed around the country. And of course, if you are looking for a better package with higher barrier protection for your products, then we may like to get another reinforced metallized layer into the foil laminate.

3 Great Final Package Profile

When the medicine tablet is filled on the machine,  the foil roll is going to be converted into excellent 3sides sealed sachet, which brings eye-catching effect to the branded products.

4 High Mechanical Strength

This reinforced laminated foil is achieved with great mechanical strength, with some standard items as below.

• Tensile Strength
• Sealing Strength
• Anti-puncture Strength
• Burst Impact Strength
• Anti-pressure Property

The above tests are performed against each order, upon customer requirements, and you may check the exact values of this foil material in the Technical Date Sheet part of this post.

In our daily QC work, there is an more easy and reliable method to check if the bag strength is enough to meet the various conditions in the operations of filling, transport, loading and unloading, distribution. We perform drop test against each order, of course, the standard for this drop test should be decided against customer needs.

Here, we are going to fill 454grams of coffee beans into this Matte BOPP18/White Kraft 45g/LDPE foil pouch, and perform drops for 5 times, and check if there is any breakage for the package.

You are advised to watch the video below.

You can judge from the video, the package stays well after 5 drops, really great physical strength.

5  Easy Tear from the Sawteeth

Usually, sawteeth can be achieved during the cuting of the roll foil on the filling machinery, and it will enable the three sides sealed pouch sachet to be torn easily against this Matte BOPP18/White Kraft 45g/LDPE foil.

Here, you can watch the video below for a further understanding.

Package Dimension and Filled Level

For the filling process, the filled effect matters much, of course,  and that is depending on the package dimension and the products filled. Against 10ml of medicine tablet, we perform the filling test here, and below picture shows the filled line, excellent!

Watch the video below to have a further understanding on the dimension test and filled level.

Below dimension test report includes all the details, you can just forward to your customer for reference.

Medicine Tablet Bag-5g-3 Sides Seal Sachet-W65xH105 mm -Packaging Dimension Test#RTLR-065

Artwork Printing

A good creative artwork matters much more than most people expect, as most people tend to buy a product they feel good for.

For the printing produce in our plant, we are able to achieve the artwork in maximum 10 colors. With in-line print defect inspection system, more than 98% of the common print defects can be removed, you may have a further understanding by below video.

We will have to request a minimum order quantity of 500kgs per design against customer artwork. As to print each color, there will be a tank of printing inks offered to the rolling print cylinder.

If the customer just start up their business, and he would like to initiat his business at the lowest cost, he may try clear unprinted film, and plan a logo printing when the business goes bigger.

5 grams Medicine Tablet 3Sides Sealed Sachet Dieline

Here is dieline for this 5 grams medicine tablet 3sides sealed sachet, with PDF file attached.

Medicine tablet-5g- 3 Sides Sealed W65XH105- 5mm edge seal Dieline Artwork Design Template R065

The artwork design template should be helpful when you plan to print your logo and eye-catching artwork on this coffee bag, and you may just download it and send it to your design to fill the creative artwork. You are advised to feedback to us with Illustrator or PDF file with high quality (>= 300PPI)

Technical Data Sheet of 5 grams Medicine Tablet 3Sides Sealed Sachet

this is the technical data sheet with our laboratory tests on the finished foil for medicine tablet, the values are reliable and ensure it running well on your machine.



Some main items are listed as below.

1. Dimension Tolerance
2. Print Appearance
3. Yield (grams per square meter)
4. Tensile Strength (Mpa)
5. Elongation Rate  (%)
6. Coefficient of friction, short as COF
7. Solvents Left (mg/m2 )
8. Sealing Strength (N/15mm)
9. Sealing Conditions
10. Bond Strength (N/15mm)
11. Burst Impact Strength (J)
12. Anti-Puncture ability (N)
13. Drop Test Ablity (cm)
14. Anti-pressure ability (kgs)
15. Water Vapor Transmission Rate (g/m2/24hr)
16. Oxygen Transmission Rate (cc/m2/24hr)

You are welcome to reach us if you have any questions regarding the test or you need further test against any items.

More Sustainable Options

With increasing burden on the plastic pollution, more and more products are now seeking for packages which are more sustainable, like compostable packages, recyclable mono materials packages, plant-based materials packages. They all proves to be more eco-friendly than the traditional multilayer packages which are even very difficult to be recycled.

1) Home compostable film material packages

Thanks to the fast development of plant-based film materials, now we are able to present the multi-layer standup pouch and roll foils in full home compostable options.

The compostable substrate films are as below.

1. BOPLA Film
2. PLA+PBAT Film
3. Kraft Paper
4. Metallized Paper
5. Cellulose Paper
6. Metallized Cellulose Paper
7. PBS Film

Based on the compostable substrate film, we are developing kinds of multi-functional packages for various applications, as below

1. High barrier performance packages, for roasted coffee beans, nutritions, milk powder, snacks or biscuits.
2. Alkaline resistant packages for hand wash, laundry cleaning chemicals etc
3. Frozen packages, like fish, noodles, or soup products
4. Vacuum packages for vegetables, rice, red beans etc
5. Hot filling packages for juice
6. Microwave packages

Along with the extentions of compostable film materials, more and more products are now starting to get well packed in home compostable packages, with some well-applied foil structures as below.

Biodegradable Foil Laminate	WVTR (g/m2/24hr)	OTR (cc/m2/24hr)
BOPLA40/PLA+PBAT60	62.2	267
Cellulose30/PLA+PBAT60	131.5	5.6
Kraft Paper45g /PLA+PBAT60	44	742
Kraft Paper45g/BOPLA40	41	380
Metallized Paper69g/PLA+PBAT40	27	127
Cellulose30/Metallized Cellulose20/PLA+PBAT60	23	0.16
Cellulose30/Metallized Cellulose20/BOPLA40	25	0.12
Metallized Paper 69g/Cellulose30/PLA+PBAT60	5.6	1.12
Kraft45g/Metallized Cellulose20/PLA+PBAT60	26	0.22
Cellulose30/Kraft45g/PLA+PBAT60	19	117.2
Cellulose30/Metallized Paper69g/PLA+PBAT60	8.9	1.1

You may have a further understanding on the biodegradable home compostable materials and pouches here.

2) Mono Materials Recyclable Pouch Packages

Mono meterials pouch packages are truly recyclabled, as they can be easily processed into plastic granules which can be used again for other applications. However, for the traditional multilayer laminates, take PET/LDPE for example, it is difficult to be processed, as PET and LDPE are quite different material, and can not be melted under the same conditions. That’s why momo materials pouch packages are becoming so widely popular in the packaging field, and highly reputed in the consumer market.

At present, mono materials pouch are basically divided into Polyethylene channel and Polypropylene channel, with polyethylene channel much more popular, as they can be converted into kinds of standup pouch packages with relative high performance.

Here we list the film materials that can be well intended for mono-materials recyclable pouch packages.

1. MDOPE Film
2. BOPE Film
3. APE Film
4. LDPE Film
5. LLDPE Film
6. CPE Film
7. ABOPP Film
8. CPP Film
9. VMCPP Film
10. VMBOPP Film

Various foil laminates can be achieved based on above film materials with different properties, which is intended to meet the particular requirements for specific product. Some foil laminates are well-known as below.

1. MDOPE/APE
2. MDOPE/LDPE
3. MDOPE/EVOH-LDPE
4. MDOPE/HDPE/APE
5. MDOPE/BOPE/APE
6. BOPE/APE

Upon our experience, mono materials pouch can be well intended for medicine tablet.

You may have a further understanding on the recyclable mono materials and pouches here.

How to fill medicine tablet into 3sides sealed sachet out of film rolls

This is a durable and high speed automatic filling machinery especially developed for medicine tablet that can achieve the three sides sealed pouch package from 2g to 1000g. Upon our experience, if the customer would like to get a durable machinery for their long-term business, this would be a fine choice.

Here is the below for the working of this amazing machinery.

About the manufacturer

Qingdao Tongli Packaging Products Co., Ltd is a professional and reliable flexible converter and package print service supplier located in Qingdao, China more than 10 years, with competitive engagement in household cleaning chemicals, coffee packages, spout doypack package, dry nuts packages, pet food packages and human food applications.

We are now working with our customers in a long-term partnership around the world. You may just rely on us if you would like to get sustainable and reliable supply for your expect packages.
